Section 10: Packaging
Assembly at Tier 1(Wire Harness Assembly Plant)
Unpacking:
TPA as received, The TPA are locked in place in the pre-lock position. If the TPA is in final
lock follow the service section in section 5.
Handling in Plant:
Harness build board/fixture: Molex recommends moving the cell pack box or box to the line,
this will insure against damage. Parts should remain in Molex cell pack until assembled placed
on a harness assembly build board.
