molex MX150 - Page 61

APPLICATION SPECIFICATION
REVISION: ECR/ECN INFORMATION: SHEET No.
EC No:
ABC2001-9999
1
DATE:
2008/16/03
TITLE:
MX150 Application Guide
61 of 62
DOCUMENT NUMBER: CREATED / REVISED BY: CHECKED BY: APPROVED BY:
AS
-
33472
-
100
Brian Zelinski Steve Verzyl Scott Marceau
TEMPLATE FILENAME: APPLICATION_SPEC[SIZE_A](V.1).DOC
Section 10: Packaging
Bulk Pack with 4 Compartments
Female 2x2 1x3
Male 2x2, 2x3, 2x4, 1x2, 1x3, 1x4,1x5, 1x6
Male 16 way Hybrid
Bulk Pack
MX150 Seal Plug
Male 1x4 through 1x6
Male 2x3 through 2x8
Male 16 way Hybrid
Cell Pack
Female 1x4 through 1x6
Female 2x3 through 2x10
Female 16 way Hybrid
Male 2x10
