Section 3: Connector Assembly
G. Harness taping recommendations
Industry standard for harness taping: Molex recommends tape should
be a minimum of 30mm from the back of connector housing.
TPA must be seated before any tape is applied to the harness!
Tape must not contact the back of connector housing!
30 mm
