Section 1: Product Introduction MX150 System
Features and Benefits
:
• Pre-assembled connector housings, seals and TPA components
• Simple crimp, poke and plug application
• Integral Terminal Position Assurance (TPA)
• Integral two way, mat and interface seals designed and tested to IP
67 and SAE USCAR-2, Rev 3 standards
• Easy terminal extraction and insertion
• Compatible with a wide range of UL (22 to 14 AWG) and SAE
Automotive (22 to 14) style wires
• Integral locking latch with secondary connector position assurance
(CPA) option
• Applied cost savings
• No need to crimp individual wire seals
• Locks terminals into housings and prevents terminals from backing
out
• More than just waterproof, a true sealed connector system tested
under submersed conditions
• Quick, low cost field repairs
• Supports a wide range of power and signal applications
• Assures positive mating of connector and prevents accidental
disengagement during high vibration and severe shock application
