Section 9: Troubleshooting
B. MX150 16 Way Male Hybrid
Issue: Damage to Orientation Feature Shorting Bar Terminal
Proper Alignment of
Shorting Bar Orientation
Feature Un-damaged
Damaged Terminal Orientation
Feature Shorting bars not
lifted
OK
