molex TM42 - Page 11

14
Lift the Feed Finger Up
Terminal Strip Feeding
Drag Frame
Rotate Drag Cam
Either Direction
to Raise or to Lower
Drag Frame
First Terminal
Above Anvils
Drag Finger / Anti-Back Up Finger
Lift up to Feed Terminal Strip
Release to Apply Drag on Terminal Strip
Terminal Strip Feeding
First Terminal
Above Anvils
"T" Style
"T2" Style
Drag Cam
LOADING THE TERMINAL STRIP
Fig. 2
