18
Press Ram at Bottom
of Full Down Stroke
Terminal in Position
over the Anvils
Hex Wrench
Conductor Punch
Insulation Punch
Conductor Anvil
Insulation Avil
M4 x 20 Lg. S.H.C.S.
M4 X 50 Lg. S.H.C.S.
Anvil Mounting Screws
PUNCH & ANVIL ALIGNMENT
Fig. 4
