34

Hold Down

Spring

Hold Down

ShaftConductor

Punch

Insulation

Punch

Front

Plunger

Striker

Front Cut-Off

Plunger

Cut-Off

Plunger

Spring

Front

Plunger

Retainer

Insulation Anvil

Conductor Anvil

Front Spacer

Tooling Key

Rear Plunger Retainer

Rear Spacer

Cut-Off

Blade

Cut-Off

Plunger

Spring

Rear Cut-Off

Plunger

Rear

Striker

Track

Base

Wire

Stop

Rear Cover

Front

Cover

T2 DUAL CARRIER (GENERIC)

Fig. 12
