1. Using both hands to support the Drip Tray, keeping it parallel to the
ground, push up untill the bottom of the Drip Tray is above the top of the
Ramp Brace Strap.
2. Slide Drip Tray over the Ramp Barce Strap and lower the Drip Tray
down when it is clear of obstructions ensuring that the tray always
remains parallel to the ground.
3. Visually inspect the Drip Tray for oil and recycle or dispose of oil if
present.
4. Clean the outside of the Drip Tray if any oil is present.
5. Relace the Drip Tray following the installation instructions.
DRIP TRAY INSPECTION & SAFETY INSTRUCTIONS
STEP 1
STEP 2
STEP 3
STEP 4
STEP 5
STEP 6
FIG 21
When handling and disposing of materials the correct procedures and
regulations must be followed. Be familiar with the regualtions on handling
and disposing of Hydraulic Oil before using the Drip Tray. This also applies
if an absorbent material is used in the Drip Tray.
