Over Drive Lock-Out Switch
To lock out overdrive for towing or direct drive transmission operation, push in on
button located on end of shift lever. The indicator light on the lever will be lit. To return
to over drive operation, push button in and release it. The indicator light on the lever
will go out.
Tire Rotation - Workhorse Chassis
Tires should be rotated every 6,000 to 8,000 miles following the diagram below.
Monarch 9-5
MONACO
2000
Chassis Information
Chassis Information
5
Tire Rotation with Spare Tire
Wheel Nut Torque Order
FRT
1
8
4
10
6
2
7
3
9
!
WARNING !
Be sure to tighten wheel nuts in proper sequence and to the proper torque.
Damage or injury could occur.
