Mongoose M80i - Page 22

SIREN / BONNET
GN
BONNET
BATTERY BACK-UP
GN
STANDARD
BONNET
BUILT-IN TURBO TIMER WIRING
Must use immobiliser circuit # 1 for ignition
Ignition barrel
Ignition sense wire
+12v permanent

CUT ignition wire
Immobiliser circuit #1
Use immobiliser circuits #2 & #3 for other circuits
POWER
TRIGGER
BONNET
TRIGGER
BONNET
