Monitor Audio 100 series User Manual

G o o d 100 Series 2-way Loudspeakers
All 100 Series loudspeakers incorporate proprietary technologies and materials found in our
award-winning Bronze and Radius in-room loudspeakers. 100 Series models are 2-way
designs that combine advanced MMP
®
II bass drivers with Monitor Audio’s trademark
C-CAM
®
gold dome tweeter to provide high-performance sound, ease of drive, and wide
frequency response and dispersion. Optimum imaging and set-up are established via a
pivoting tweeter and high-frequency (+3dB / 0dB /-3dB) level adjustment.
B e t t e r 200 Series 2-way Loudspeakers
The step to the 200 Series 2-way loudspeakers is dened by upgrades in driver technology
and control features. All 200 Series loudspeakers incorporate proprietary technologies and
materials found in our highly acclaimed Silver in-room loudspeakers. 200 Series models
marry C-CAM
®
bass drivers with a more highly specied version of the C-CAM
®
gold
dome tweeter. Optimum imaging and set-up are established via a pivoting tweeter, high-
frequency (+3dB / 0dB / -3dB) level adjustment, and Boundary Compensation (on / off)
controls. The Series 200 2-way loudspeakers provide extended high-frequency response
to 30kHz, and higher output and power handling capacity than the 100 Series 2-way
models.
B e s t 200 Series 3-way Loudspeakers with IDC
®
200 Series 3-way loudspeakers feature our unique Inverted Dual Concentric (IDC
®
) driver
module. The IDC
®
driver module houses a 4-inch C-CAM
®
midrange and 1-inch C-CAM
®
gold dome tweeter. 200 Series 3-way models combine C-CAM
®
bass drivers with an
IDC
®
driver module to provide rich midrange detail, higher system output, greater power
handling, and superior vocal intelligibility and sound localization than 200 Series 2-way
models. Optimum imaging and set-up are established via the pivoting IDC
®
, high-
frequency (+3dB / 0dB / -3dB) level adjustment, and Boundary Compensation (on / off)
controls.
F l a g s h i p 300 Series 3-way Loudspeakers with IDC
®
Our agship 300 Series 3-way loudspeakers provide THE BEST Monitor Audio in-wall and
in-ceiling loudspeaker options for music and home theater applications. All 300 Series
loudspeakers incorporate proprietary technologies and materials found in our award-
winning Gold in-room loudspeakers. 300 Series 3-way models marry C-CAM
®
bass
drivers with RST
®
cone proles and a cast-aluminum driver chassis with an IDC
®
driver module to provide deeper bass, higher system output, and greater power
handling than the 200 Series 3-way models. Like the 200 Series 3-way loudspeakers, the
300 Series models provide rich midrange detail, and superior vocal intelligibility and
sound localization. Optimum imaging and set-up are established via the pivoting IDC
®
,
high-frequency (+3dB / 0dB / -3dB) level adjustment, and Boundary Compensation (on /
off) controls. The W380LCR in-wall loudspeaker adds a midrange-frequency (+3dB / 0dB
/ -3dB) level adjustment for system tuning and a die-cast aluminum front bafe for added
rigidity resulting in superior bass articulation.
Performance guide
F X Surround Loudspeakers
The C265FX and C380FX models feature selectable dipole (diffuse sound) or bipole (direct
sound) modes for use as rear surround speakers in discreet home theater applications.
The surround mode can be selected via a front-mounted switch for both models. The
C380FX also features a 12-volt trigger input for automatic surround mode switching. The
C265FX and C380FX models use dual 1-inch C-CAM
®
gold dome tweeters mounted at a
precise xed-angle for optimized performance. The C265FX has a 6.5-inch C-CAM
®
bass
driver. The C380FX has an 8-inch C-CAM
®
bass driver with RST
®
cone prole and a cast-
aluminum driver chassis.
T 2 Stereo Loudspeakers
Our T2 Stereo models feature dual, independent pivoting 1-inch C-CAM
®
tweeters, and
6.5 inch (C165T2) or 8-inch (C180T2) MMP
®
II dual wound voice coil bass drivers for high
performance stereo sound from a single speaker. The T2 models are ideal for bathrooms,
hallways, or any area where space does not allow for stereo pairs.
8˝ In-Ceiling
C180 In-Ceiling 2-Way
•
C280 In-Ceiling 2-Way
•
C280LCR In-Ceiling 3-Way
•
C380LCR In-Ceiling 3-Way
•
C380FX In-Ceiling Surrounds
•
C180T2 In-Ceiling Stereo
•
6.5˝ In-Ceiling
C165 In-Ceiling 2-Way
•
C265 In-Ceiling 2-Way
•
C265LCR In-Ceiling 3-Way
•
C265FX In-Ceiling Surrounds
•
C165T2 In-Ceiling Stereo
•
8˝ In-Wall
W180 In-Wall 2-Way
•
W280 In-Wall 2-Way
•
W280LCR In-Wall 3-Way
•
W380LCR In-Wall 3-Way
•
6.5˝ In-Wall
W165 In-Wall 2-Way
•
W265 In-Wall 2-Way
•
Performance at a glance
Good Better Best Flagship FX Surround T2 Stereo

Monitor Audio 100 series Specifications

General

Nominal Impedance	8 Ohms
Type	2-way
High Frequency Driver	25 mm C-CAM Gold Dome tweeter
Series	100
Recommended Amplifier Power	30 - 100 W
