Setting up the Gold FX

5IF(PME'9nTBSFJOEFQFOEFOUTQFBLFSTUIBUDBOCFUBJMPSFEUPCFFJUIFSMFGUPSSJHIUIBOEFEBUUIFˍJDLPG

a switch. Likewise, they can be operated in either di-pole or mono-pole modes. The default factory setting

is mono-pole.

In mono-pole mode, only the main driver and tweeter will be active. In di-pole mode, the main tweeter is

EJTFOHBHFEBOEUIFTJEFESJWFSTBOEUXFFUFSTBSFBDUJWF5IFGSPOUˌSJOHUXFFUFSTBSFPVUPGQIBTFXJUIUIF

PUIFSUXFFUFSBOENJECBTTVOJU*UJTSFDPNNFOEFEUPJNQMFNFOUUIJTDPOˌHVSBUJPOXIFOVTJOHUXPQBJST

Gold FX as part of a 7.1 channel system, with the Gold FX’s taking up positions on side and rear walls. Please

note, it is essential they are positioned correctly when used in a 7.1 channel system. Please refer to the

switch positioning images on pages 7 and 8.

/05&#FGPSFBEKVTUJOHBOZTXJUDIFTQMFBTFFOTVSFUIBUUIFBNQMJȚFSJTBUUIFWFSZMFBTU

UVSOFEPș5IJTXJMMIFMQUPQSPUFDUUIFBNQMJȚFS

Tweeter Attenuation Switch: This switch adjusts the level of the main high

frequency tweeter unit. In the middle position, there is no attenuation. Placed

in the ‘-’ position, the high frequencies will be attenuated by 3dB. Placed in the

‘+’ position, the high frequencies will be boosted by 3dB.

Location Switch: This switch is used when determining the location of the Gold

FX’s. Please refer to the illustrations on pages 7 & 8 for correct positioning.

5IJTXJMMPOMZNBLFBEJˋFSFODFXIFOJOmEJQPMFnNPEF

Mono-pole/ Di-pole Switch: This switch determines the actual mode of

the Gold FX. When part of 5.1 systems as a rear speaker, set the switch to

mono-pole. Although there is nothing wrong with experimenting and trying

the switch in the di-pole mode. If part of a 7.1 system as side speakers, set the

switch to di-pole. If using 4 Gold FX’s (side and rear) set them all to di-pole

mode. Please see the illustrations on pages 7 & 8 to determine the setting of

the ‘Location Switch’ depending on system set up.

If you are using the 12v trigger, set the switch to monopole mode. The trigger

will switch a relay to enable the di-pole mode.

12 volt Trigger: /PUTIPXO5IJTGFBUVSFJTQSFTFOUPOTPNF"7BNQMJˌFST*U

is possible to customise the 12v trigger to switch the speakers to di-pole for

certain sources. For example, multi-channel music should be listened to in

mono-pole mode, however, movies should be listened to in di-pole mode. This

feature automates the switching between the two modes. Please refer to your

"7BNQMJˌFSNBOVBMGPSGVSUIFSJOTUSVDUJPO

Gold Series6
