4
© Monitor Audio 2005 RS Rev 5
Your Silver RS1
Don't be fooled by the size. The most compact loudspeaker of the Silver RS
range delivers a sound that's anything but small, rivalling far more costly
'compact monitors' for bass extension, mid-range resolution and precise
imaging within a stunningly open soundstage. Allied with ‘figure 8’ cross-
bracing to reduce cabinet resonance an excellent stand mount loudspeaker has
been created.
Because the RS1 offers great performance from a small speaker, it lends itself
to a wide range of positioning options. The RS1 will perform equally well no
matter how itis positioned. The RS1 can beplaced on a stand, ora bookshelf.
To remove the grille, carefully prise it away from each cabinet section at a time.
There are two sets of fixing points on this product. One above the drive unit,
the other below it. Refitting is the opposite of removing. Ensure it is correctly
orientated.
For information on wiring and system configurations, please refer to pages 13,
14 and 15.
Frequency
Response
(Crossover
Frequency)
Sensitivity
(1W@1m)
Nominal Impedance
(Ohms)
Power
Handling RMS
(W)
Recommended
Amplifier power
output.
(W)RMS
43Hz –30KHz)
(3.3KHz)
90dB 6 80 25 – 100
Drive Unit
Complement
Cabinet
Design
Product External
Dimensions Inc Grille
and Terminals.
cm (inch)
Weight
Kg (lb)
Finishes
1 x 6" C-CAM
®
Bass
mid-range. 1 x 25mm
Gold Dome C-CAM
®
tweeter.
Rear ported,
bass reflex
31H x 18.5W x 28D
(12
3
/
16
" x 7 1/4"
x 11")
6
(13.2)
Black Oak,
Rosenut, Walnut,
Natural Oak or
Cherry real wood
