9
© Monitor Audio 2005 RS Rev 5
Your Silver RS FX
Designed as part of the Silver RS home theatre system, the RS FX surround
speaker combines amazing performance with modern, discreet design that can
be flush mounted on a wall using the enclosed wall brackets. The attractive
curved grille and end caps conceal a rigid angular cabinet construction along
with Monitor Audio’s renowned and highly acclaimedC-CAM
®
driver technology
and C-CAM
®
tweeters.
By using low slope linear phase crossover design, Monitor Audio has
engineered the Silver RS FX to have seamless integration and almost perfect
180-degreedispersion characteristics. Whilst thebass driveralways operatesin
phase, the tweeter section can be configured to operate as a bi-pole or di-pole,
which means the Silver RS FX, can just as easily be used on sidewalls in a more
advanced 7.1 system.
Please note, if used in a 7.1 channel system, the RS FX’s are left and right
handed. This isindicatedon the terminal panelon the back of the product.
To remove the grille, carefully slide it around the cabinet. Refitting is the
opposite of removal. The grille cannot be removed with the cabinet secured to
the wall.
Frequency
Response
(Crossover
Frequency)
Sensitivity
(1W@1m)
Nominal Impedance
(Ohms)
Power Handling
RMS (W)
Recommended
Amplifier power
output.
60 Hz-30 KHz
(2.2KHz)
89 dB 6 100 10-100W
Drive Unit
Complement
Cabinet
Design
Product External
Dimensions Inc Grille
and Terminals.
cm (inch)
Weight
Kg (lb)
Finishes
1 x 6" C-CAM
®
bass/midrange
driver, 2 x 25mm
Gold dome C-CAM
®
tweeters.
Sealed
Cabinet
28.5H x 29W x 13D
(11 1/4" x 11 7/16" x
5 7/32")
4 (8.8)
Black Oak,
Rosenut, Walnut,
Natural Oak or
Cherry real wood
