7
© Monitor Audio 2005 RS Rev 5
Your Silver RS8
Silver RS8 is the new 2 ½ way floor-standing flagship model of the range and
builds on the considerable musical strengths of the smaller Silver RS6 by
providing a still wider bandwidth, high power handling, greater efficiency and
more effortlessly realised dynamics.
Rigid construction achieves a clean, un-boxy sound. The RS8 employs multiple
bracing positioned at critical resonance nodes. Its slim proportions and
detailing positively contribute to sound quality by reducing diffractioneffects.
The Silver RS8 utilises three 6 inch C-CAM
®
drivers. The lower two units handle
bass only, the upper unit provides punchy upper bass and a clear, natural mid-
band rightup to the crossover pointwith the tweeter at 3KHz.
To remove the grille, carefully prise it away from the cabinet sections at a time.
There are four sets of fixing points on this product. One above the mid-bass
drive unit, one below it, the third is above the bass drive unit, with the fourth
being below it. Refitting is the opposite of removing. Ensure it is correctly
orientated.
Tosafely fitthe plinth and spikes please referto pages 12 and 13.
For information on wiring and system configurations, please refer to pages 13,
14 and 15.
Frequency
Response
(cross over
Frequency)
Sensitivity
(1W@1m)
Nominal
Impedance
(Ohms)
Power Handling RMS (W)
Recommended
Amplifier power
output.
(W) RMS
33Hz – 30KHz
(3 KHz)
91dB 6 175 40 - 175
Drive Unit
Complement
Cabinet
Design
Product External
Dimensions.
cm (inch)
Plinth
Dimensions
(foot print)
cm (inch)
Weight
Kg (lb)
Finishes
2 x 6" C-CAM
®
Bass Drivers, 1x 6"
C-CAM
®
Mid-range
Driver. 1 x 25mm C-
CAM
®
Gold Dome
tweeter.
Balanced velocity
