Monitored Therapeutics, Inc. © Copyright 2020 9 P/N 45-50035 Rev. K, 2020-10-21
7.2.2. The GoSpiro must be only exposed to relative humidity levels between
15%RH to 95%RH (50hPa maximum), non-condensing.
8. GETTING STARTED
8.1. The GoSpiro is designed to enable two different mouthport positions for holding
by either right or left handed individuals.
8.2. If you use your right hand to hold the GoSpiro, install the Turbine Assembly as
following (steps showing in Figure 3):
8.2.1. Insert the Turbine Assembly into the body of the GoSpiro with its mouthport
in the direction away from of the purple power button.
8.2.2. Turn the turbine assembly clockwise 90° and it will click-lock in place.
Caution: Do not force the turbine beyond the 90 degree position when inserting or
removing the turbine from the GoSpiro housing. Note the direction of insertion and
removal for left or right hand use.
Figure 3 Insert transducer for right hand use
8.3. If using your left hand to hold the GoSpiro is more comfortable for you, install the
Turbine Assembly as following (steps showing in Figure 4):
8.3.1. Insert the Turbine Assembly into the body of the GoSpiro with its mouthport
towards the purple power button.
8.3.2. Turn the turbine assembly clockwise 90° and it will click-lock in place.
Caution: Do not force the turbine beyond the 90 degree position when inserting or
removing the turbine from the GoSpiro housing. Note the direction of insertion and
removal for left or right hand use.
