Mono Eco Connect Plus FG159 User Manual

Eco Connect Convection Ovens | 4/5/7/10-Tray | Steam Installation and Operation Manual
14
MONO FG1BX-UK-MAN-0200 | Rev. A23 (March 2023)
4. Installation
Power
WARNING  An electrical socket must be protected by a 30mA Type A Residual Current
Device (RCD) before installation and commissioning of the oven.
 Always fit a wall-mounted isolator switch to isolate the oven completely from the
electrical supply in an emergency. The isolator must be visible, labelled, and
easily accessible by an operator.
 Always check electrical requirements on the nameplate before connecting power.
Figure 3: Main power supply connections
NOTE
 L2 and L3 are for three-phase installations only.
 See the Specifications section for electrical specifications.

Mono Eco Connect Plus FG159 Specifications

General

Brand	Mono
Model	Eco Connect Plus FG159
Category	Convection Oven
Language	English
