PART 4 4/5 Tray 40cm x 60cm Oven Spares Section
Oven Code FG153
Figure 33: Rear view with outer sheeting removed (FG153)
A. Motor and Element ....................... (Part 4 / Section 1 on Page 88)
B. Main Panel ................................... (Part 4 / Section 2 on Page 89)
C. Damper and fan ........................... (Part 4 / Section 3 on Page 90)
D. Water System ............................... (Part 4 / Section 4 on Page 91)
E. Baking Chamber and Door Parts . (Part 4 / Section 5 on Page 93)
