Eco Connect+ Convection | 4/5/7/10-Tray | Steam Installation and Operation Manual
16
MONO FG1BX-UK-MAN-0300 | Rev. C23 (July 2023)
4. Installation
Power supply
WARNING An electrical socket must be protected by a 30mA-rated Type A Residual Current
Device (RCD) before installation and commissioning of the oven.
Always fit a wall-mounted isolator switch to isolate the oven entirely from the electrical
supply in an emergency. The isolator must be visible, labelled, and easily accessible
by an operator.
Check that the electrical requirements on the oven’s information plate match the supply
before connecting the power cable and turning the power on for the first time.
Figure 3: Main power supply connections
NOTE L2 and L3 are for three-phase installations only.
See the Specifications section for electrical specifications.
