ZKH1 INSTALLATION
INSTRUCTIONS
OPTION 2
For dispenser model
using full-width
trim
Step 1
Remove handles
Step 2
Remove trim
ZKH1 Trim Kit
Custom Handles with 1/4" Panels
23
• Carefully remove the Phillips head screws from the
door handle endcaps, top and bottom.
• Open door to 90°. Remove the screws from the
full-length aluminum handle of the freezer door.
• Retain screws, discard handle and endcaps.
Remove door panel trim above and below dispenser. Lift
off dispenser trim. Retain screws and trim.
To Next Page
