Take Inventory of your MTK Parts, Hardware and Tools
Tower Parts Mounting Base Parts
Top Section
x 1
Right Leg
x 1
Left Leg
x 1
Wire Through
Grommet
Wire Through
Grommet
Heim Joint
Jam Nut
x 4
Heim Joint
x 4
All Round
Navigation
Light
x 1
Swivel
x 4
Base Mount
x 4
Below Deck
Plate
x 4
Quick Release
Knob
x 2
Base Pad
(black rubber)
x 8
M10 x 40 Bolt
x 8
Hardware
Shown Actual Size
M12 x 35 Bolt
x 2
M8 x 60 Bolt
x 8
M12 x 85 Bolt
x 4
M10 Nylock Nut
x 8
M12 Nylock Nut
x 4
M8 Nylock Nut
x 8
M8 Washer
x 16
M12 Washer
x 8
Tools Included
10mm Drill Bit
Items and Tools Needed for Installation
Required
Optional
Vacuum for 
berglass shavings from drilling
Throw Tarps, Blankets or Towels (to cover your boat)
1/4” (6 mm) or 3/8” (10mm) thick marine grade plywood
(as needed to reinforce mounting areas of your boat deck)
Silicone Sealant
Reversible Drill with 1/8”, 1/4“, 5/16”, 3/8“ and 1/2” Drill Bits
Adjustable Wrench (crescent wrench)
Socket Wrench with 13mm, 17mm and 19mm metric sockets
Allen Wrench sizes - 6mm, 8mm and 10mm
Torque Wrench (no pneumatic wrenches)
Weather tight electrical connectors
Sharp Craft Knife or Single Edge Razor Blade
Masking Tape, Tape Measure and Pencil
One or Two Friends to help hold and hand things as needed
Safety Glasses (always use when drilling berglass or metal)
Oval Cap
(black rubber)
x 4
Allen Keys for Bolts
x 3
