• Connection of active stage monitors.
A
/
B
/
C
/
D
/
E
/
F OUTPUTS
◗
INPUTS
of active stage monitors
(up to 10 each output, parallel connected).
CONNECTIONS
FIG.
2
- A/B/C/D/E/F MONITOR OUTPUTS
ACTIVE STAGE MONITORS
48
USE HEAVY GAUGE SHIELDED CABLES
MONO JACK CONNECTOR
for the A
/
B
/
C
/
D
/
E
/
F INSERTS as OUTPUTS
UNBALANCED XLR FEMALE CONNECTOR
for the A
/
B
/
C
/
D
/
E
/
F OUTPUTS
1 GND Ground
2 + Hot
3 GND Ground
(IEC 268 standard)
UNBALANCED XLR MALE SOCKET
JACK SOCKET
STEREO JACK CONNECTOR for the A
/
B
/
C
/
D
/
E
/
F INSERTS
APPENDIX
