Montarbo Spot 2500T User Manual

PROFESSIONAL LOUDSPEAKER SYSTEM PROFESSIONAL LOUDSPEAKER SYSTEM
PROFESSIONAL LOUDSPEAKER SYSTEM PROFESSIONAL LOUDSPEAKER SYSTEM
7
ENGLISH
user's manual
CONTROLS AND CONNECTIONS PANEL
1 - AC LINE IN: ac line input connector.
This is the mains supply inlet socket with type A PowerCon
®
(blue)
connector which guarantees a reliable, vibration-proof contact.
Connect it to the mains socket using only a mains cable with suitable
conductors capable of handling the current involved, equipped with a
ground conductor, marked with the applicable, country specic, safety
approvals and tted with a power plug certied for the actual current
value. Refer to par. 3.2 for connector wiring instructions.
When installing the speaker system, make sure that it is easy to get to this
socket and to the mains plug.
2 - AC LOOP OUT: power link connector.
This type B (gray) PowerCon
®
connector allows you to link other devices
to the mains power (max current available: 13,6A).
Refer to par. 3.2 for connector wiring instructions.
Maximum current available from this connector is limited. Refer to par. 3.2.
3 - Mains ON/OFF switch.
Even when the switch is in the 0 (off) position, the AC LOOP OUT
connector (2) is connected to the mains power. Devices connected to it
must be switched off by means of their power switches.
4 - Input connector.
It is a balanced, line level input, that may be fed by balanced or
unbalanced sources. Connect it to the mixer output. It is a 3-pin female XLR
connector, balanced. For wiring details, refer to par. 3.3.1.
5 - Input link connector. It is wired in parallel to the input connector (4) and
it makes possible to send the input signal to other equipment (usually to
other self-powered speaker systems). For wiring details refer to par. 3.3.1.
For details about parallel connection of multiple systems, refer to par. 3.4.
6 - Master volume control that adjusts the system's volume (of both full-
range and bass cabinets).
7 - RJ45 sockets of the two DATA ports: they are intended for connection
to the Montarbo USBNet control network: a Montarbo LD2.4 USBNet
interface and/or another active speaker of the FULL, SPOT and WIDE series.
Use standard 8 poles ETHERNET cables (CAT5 or higher).
For more detailed information, refer to par. 4.3.
8 - SUB OUT socket for driving an external active sub-woofer.
By selecting the suitable preset (refer to par. 4.2) the internal DSP may be
congured to drive a subwoofer with or without an internal crossover
lter. In the rst case the output is a wide-band signal, in the second case
the output is band-limited and suitable for most active sub-woofers.
It is a 3-pin male XLR connector.
Refer to par. 3.3.1 for wiring details.
9 - SPEAKON
®
socket for the connection of the SPOT15B bass cabinet.
Use the supplied cable.
If a longer cable is needed, it may be assembled following the wiring
instruction of par. 3.3.2.
