Montarbo Spot 2500T User Manual

PROFESSIONAL LOUDSPEAKER SYSTEM PROFESSIONAL LOUDSPEAKER SYSTEM
PROFESSIONAL LOUDSPEAKER SYSTEM PROFESSIONAL LOUDSPEAKER SYSTEM
9
l
p
o
n
q
r
m
1+/1 signal
2+/2 nc
9
ENGLISH
user's manual
CONNECTION PANEL
9 - SPEAKON
®
socket for the
connection to the full-range active
cabinet. Connect to the '8' socket.
Use the supplied cable.
If a longer cable is needed, it may be
assembled following the wiring
instruction of par. 3.3.2.
SPOT15B - CONNECTION PANEL
2.2 - SPOT2500T - model SPOT15B passive bass cabinet
l - 1 x 15” woofer , with a 4” voce coil and a powerful, shielded,
neodymium, front-mounted, magnet
.
m - Cabinet made from birch plywood, with high-impact, chip-resistant paint.
n - Steel protection grill with foam protection.
o - Bass reex vents.
p - Carrying handles.
q - Connection panel.
r - Speaker-stand adapter.

Montarbo Spot 2500T Specifications

General

Brand	Montarbo
Model	Spot 2500T
Category	Speakers
Language	English
