Monuments Edge Series - Scope of Delivery and Specifications; Technical Specifications and Data

30
D
Specications
Power 6.0 kW 7.5 kW 9.0 kW
Electric connection 400 V 3N AC 50 Hz
Size (H x W x D)
98 x 35 x 35 cm
(by optional side panels: +2,5 cm per each panel)
For sauna cabin size 6 - 8 m³ 8 - 12 m³ 9 - 14 m³
Min. size air supply and duct vent 35 x 4 cm 35 x 5 cm 35 x 6 cm
Weight without stones and packing 17 kg
Stone lling 115 kg (not included)
Fuse protection of control unit 3 x 16 A
Connection power supply - control unit 5 x 2.5 mm²
Connection control unit - heater (heater - mains)
400V 3N AC - 5 x 1,5 mm²
230V 3N AC - 3 x 2,5 mm² + N and PE(Gr) 6 mm²
Leakage current max. 0.75 mA per kW of heating power
Control unit not included
Intended use Sauna heater for use in private saunas
All cross sections of a line are minimum diameters in mm² (copper wire).
To be used with control units: that comply with the Low-Voltage Directive 2014/35/EU and the standards:
DIN EN 60335-1, DIN EN 60335-2-53, DIN EN 62233, DIN EN 62233 Ber.1 and a sauna operation control
range up to max. 115°C, and a sensor system with a safety temperature limiter of max. 139°C.
Scope of delivery
Check the delivery contents and verify that all parts are available. Missing or damaged parts should be
reported to your authorized dealer.
The standard delivery includes:
• 1 sauna heater
• 1 accessories bag with:
4 floor-standing feet
4 nuts M8
1 cable gland PG16 with counter nut
• Installation and operation manual
