Monuments Edge Series - Installation of Side Panels

To Next Page

To Previous Page

• The safety gaps between the heater and the cabin wall, as well as the protective heater

guard rail, the bench and other ammable materials change to 5 cm (see Fig. 8)

Installation of side panels

5 cm

Guard rail

Fig. 7

Fig. 8

Side panels

Side panels are optional accessories (Item 30509-3S) and can be mounted if required on

1 - 4 sides. The side panels are not only a decoration element they will also signicantly

reduce the radiant heat. This allows the reduction of the side safety gap to 5 cm (Fig. 8).

• First insert the bottom end

tongues of the panel into

the openings in the heater

shell, then put the upper

part over the top edge of

the outer shell (Fig .7).

• Secure each side panel

with 2 supplied screws

(Fig. 7).
