2022-09-07 - 35 - 2200700
If the “current” number shows 0.0, then the inclinometer
calibration has been cleared and needs to calibrated.
To calibrate the inclinometer, touch the Set to 0° button for
Pitch and/or Roll. A Confirmation message will appear
similar to the screen shown at right. When Yes is touched,
the system will be recalibrated to 0 degrees for the setting
currently being read by the inclinometer.
Retract Flow Plates and Retract Yaw Plates
Touching one of these options and then Confirm will retract the Flow or Yaw plates to 0%. This is
beneficial when storing the boat or if the actuators need further adjustment.
