MOON P-3 Stereo Preamplifier
Specifications
Configuration .......................................... Stereo
Power Supply Transformer ........................ 0.2kVA
Power Supply Capacitance ....................... 12,000µF
Class Of Operation .................................. Class “A”
Design .................................................... Feedback Differential
Single-ended inputs (RCA) ....................... 8
Input Device Type .................................. J-FETs
Input Impedance .................................... 13,500
Ω
Input Sensitivity ...................................... 200mV – 3.0V RMS
Tape Output ........................................... 1
Tape Monitor Loop ................................... 1
Output Device Type ................................ MOSFET
Balanced outputs (XLR) ........................... 1
Single-ended outputs (RCA) ..................... 1
Headphone output .................................. 1 located on rear panel
Output Impedance (Balanced) ................ 50
Ω
Output Impedance (Single-ended) ........... 100
Ω
Gain Control ........................................... RGB cs – “Shunt-To-Ground”
Gain (Balanced) ..................................... 9.5dB
Gain (Single-Ended) ............................... 6.5dB
Signal-to-noise Ratio ............................... 85dB @ full output
Maximum Output Voltage (Balanced) ......... 8 Volts
Maximum Output Voltage (Single-Ended) ... 4 Volts
Frequency Response ............................... 20Hz - 20kHz +0/-0.1dB
Crosstalk @ 1kHz .................................... -56dB
Intermodulation Distortion ....................... Unmeasureable
THD (20Hz - 20kHz) ............................... < 0.03%
Remote Control ...................................... All Aluminum Simple-Function (SRM)
Optional Phono Section ............................ MOON IPS - external
AC Power Requirements .......................... 120V / 60Hz or 240V / 50Hz
Fuse Replacement - 120V / 230V ............. 1A long slow blow
Shipping Weight ..................................... 22 lbs / 10 Kgs
Dimensions (W x H x D, inches) ............... 17 x 4 x 15
Balanced Output Pin Assignment:
Pin 1........................ Ground
Pin 2........................ Positive
Pin 3 ....................... Negative
____________________________________________________________________________________
Specifications 12
