6.
Rudder
tubes
(7244).
7.
Elevator
Tube
(7243).
8.
Elevator
andRu~lder
3rd
Link
(7101)
(two
tubes).
9.
Remove
floorboard
braces
(3937-9,
3937-10,
3937-113.
10.
Seat
Rail
Bracket
(3939-7,
3939-8
Six
bolts)
(3941
two
bolts).
11.
Stringer
assembly
doubler
(3977-1).
.12.
Fourteen
bolts
from
"Z"
rail.
13.
Sixteen
Attach
bolts
iAN
3-5A).
14.
Gas
lines
and
wires
from
wing
root.
15.
Airs_need
indicator
line,
Pitot
lines,
heated
pitot
lines
if
used.
16.
Front
mating
bolts
(two
AN
6-16A).
17.
Rear
mating
(two_
AN
P15A
and
two
AN
P17A).
18.
tension’
Bolts
(7H-16A).
NOTE:
Have
suitable
cradle
ready
for
fuselage
before
last
three
steps
of.wing
removal.
2.~
REMOVAL
OF
WING
FLAP
a
Remove
wing
flap
cover
plate
at
wing
root
(7274).
b.
Disconnect
the
flap
actuating
link
(7100).
c.
´•Remove..bir,ge
bolts
(4).
d.
Pull
the
flap
straight
back
ofT
the
wing.
3.
REMOVAL.OFAILERON
a.
Disconnect
the
Aileron
control
tube
(7241)
at
the
inboard
aileron
hinge
(2177
or
2178).
b.
Remove
three
hinge
bolts.
c.
Pull
the
aileron
straight’off
the
wing.
C.
INSTALLATION
OF
WING
COMPONENTS
1.
I~nstallation’of
Wing.
Installation
of
the
wing
asserhbly
is
a
direct
reversal
of
removal.
2..
Installation
of
Flap.
Installation
of
the
nap
assembly
is
a
direct
reversal
of
removal.
3.
Installation
of
Aileron.
Installation
of
Aileron
assembly
is
a
direct
reversal
of
removal.
j
.~_.._.
