-6 -
’
MSSTAC6 Step Motor Drive User Manual
MOONS’
www.moons.com.cn
and maintenance
INTERFACE RS-232 and RS-485 Bus
ENCODER Differential line receivers suitable for 200 KHz or greater
OPERATING TEMPERATURE 0-55°C (32 - 158°F) ambient temperature
HUMIDITY 90% non-condensing
1.5 Getting Started
To use drive models MSST5-S or MSST10-S, the following items are needed:
A compatible stepper motor
A small flat blade screwdriver for tightening the connectors (included with the drive)
A PC running Microsoft Windows 95, 98, NT, Me, 2000, or XP
The MOONS’ CD that was included with your MSSTAC6 Stepper drive
A MOONS’ programming cable (included)
To become familiar with the MSSTAC drive and Configurator Software before utilizing it in an
application, the following steps are recommended:
1. Install the STAC6-Configurator software from the CD.
2. Launch the software by clicking Start...Programs...MOONS’...STAC6-Configurator
3. Connect the drive to the PC using the programming cable supplied
4. Connect the drive to the AC power source (may be switched)
5. Connect the drive to the motor.
6. Apply power to the drive.
7. Follow the instructions on the STAC6 Configurator help screens
2 Installation
2.1 Connections wires
2.1.1 Connecting AC Power
The MSSTAC6 accepts an AC supply voltage from 94 to 135 VAC, 50/60 Hz.
The MSSTAC6-220 accepts an AC supply voltage from 94 to 265 VAC, 50/60 Hz.
Using the connector supplied connect to the AC supply as in the diagram below. Use 16 AWG wire for
Line (L) and Neutral (N). Use 14 AWG for Earth Ground (G).
Care should always be taken when working with high voltages.
In regions where the single-phase supply is higher, an auto transformer can be used to drop the voltage
to the correct level.
