MOONS’
SR4/SR8 Stepping Motor Drive User Manual
www.moons.com.cn
34HD Series1.8°
Unit: mm
Parameters
PART# CONNECTION
MOTOR
LENGTH
（mm）
MOTOR
HOLDING
TORQUE
（mN·m）
#OF
LEADS
STEP
ANGLE
（deg）
AMPS OHMS MH
MOTOR
INERTIA
(g-cm
2
)
MOTOR
WEIGHT
(Kg)
unipolar 2400 4.5 0.48 1.7
Bipolar series 3000 3.18 0.96 6.8
34HD0801-02
Bipolar parallel
66.5
3000
8 1.8
6.3 0.24 1.7
1100 1.6
unipolar 4800 4.5 0.66 2.7
Bipolar series 6500 3.18 1.32 10.8
34HD1801-02
Bipolar parallel
96
6500
8 1.8
6.3 0.33 2.7
1850 2.7
unipolar 7000 4 0.97 5.4
Bipolar series 9800 2.8 1.94 21.6
34HD2801-05
Bipolar parallel
125.5
9800
8 1.8
5.6 0.485 5.4
2750 3.8
