Moore Industries SPA2 - Dimensions

The Interface Solution Experts 7
SPA
2
Programmable Current/Voltage
Limit Alarm Trips
Figure 2. Setting the Internal Jumper for Password Security ON or OFF
SPA
READY
INPUT TRIP 1 TRIP 2
TRIP 3 TRIP 4
SELECT
DOWN
UP
COM
2
SITE
PROGRAMMABLE
ALARM
C
L
WHEN INSTALLED
WHEN INSTALLED
100mm
(3.94 in)
52mm
(2.05 in)
48mm
(1.89 in)
138mm
(5.43 in)
133mm
(5.24 in)
126mm
(4.97 in)
100mm
(3.94 in)
137mm
(5.39 in)
55mm
(2.17 in)
REMOVE PANEL
BY UNSCREWING
TOP FOUR SCREWS
SET PASSWORD SECURITY
PASSWORD SECURITY
IS OFF. NO PASSWORD
REQUIRED.
PASSWORD SECURITY
IS ON. PASSWORD
REQUIRED.
BACK
TX
+I
COM
+V
-lo Source
+lo Sink
+lo Source
+Vo
-Vo
-lo Sink
INPUT
A OUT
2
SPA TOPSIDE
FRONT
MR
Figure 1. SPA
2
(HLPRG) Dimensions
