Morco FEB-24E - Gas Valve Details and Adjustments; Burner Pressure Chart and Gas Valve Figures; PCB Adjustment Points (P1, P2, P3)

48
Gas valve details
P1 Maximum power adjustment
P2 Minimum Lighting pressure
P3 Output for central heating
adjustment
Figure 7
Burner pressure
mbar
inch wg
Output
(kW)
Natural Propane Natural Propane
23.7
18.0 35.0 7.2 14.0
7.6
2.0 4.0 0.8 1.6
Ignition
Pressure
4.0 8.0 1.6 3.20
Ø Injectors
(mm)
1.14 0.75 1.14 0.75
Figure 5
E
Figure 6
T
Figure 4
C
Chart
J2 J19
J1
P1
S4
P3
P2
S3
S1
J5
J11
J9
J10
J8
Figure 2 Figure 3
E
D
