INDEX
Page 3
INDEX
FOLDING TIPS AND TROUBLESHOOTING 35
Sheets Difficult To Feed 35
Double Sheet Feeding 35
Fold Is Not Square Or Consistent 35
Paper Will Not Stack Consistently 36
Paper Will Not Deflect When Using One Fold Or Perforating 36
Total Batch Counter Not Working 36
‘Overlap Error Keeps Appearing 36
Machine Will Not Reset 36
No Power To Machine 37
Mains Switch Cuts Out 37
Fold Roller Replacement 37
ERROR SCREENS 38
DISPATCH KIT 41
ACCESSORIES AND OPTIONS 42
RECOMMENDED SPARES 43
FUSE POSITIONS & RATINGS 45
PRODUCT RECYCLING AND DISPOSAL 46
INTRODUCTION & SPECIFICATION PAGE 4
SAFETY Do’s & Don'ts 5
THE DocuFold Pro
Labelled Photograph 7
OPERATING THE DocuFold Pro
Adjusting the Paper Gate 8
Setting the Suction Slot 8
Setting the Vacuum Bleed 9
Setting the Adjustable Side Lay 9
Setting the Back Stop 9
Setting the Air Distribution Knob 9
Setting the Air Separation Knob 9
Fold Plates 10
Roller Tilt 11
Delivery Roller 12
Emergency Stop Switch 12
Overlap 12
TOUCHSCREEN OPERATION
Touchscreen Layout 13
Paper Settings Page 14
Batch Size selection 15
Speed Selection 15
Fold Settings Pages (Pre-defined fold types) 16
Setting Fold Positions Manually (Set by Position) 17
Delivery Settings Pages 19
Status Screen 20
Run Job 21
Store Pages 23
Tools Menu 26
Touch Screen Calibration 27
PLUG IN PERFORATOR 28
Setting Perforators 31
Scoring 31
Folding Card 32
Paper Jams 32
Roller Assembly - Removal 32
Roller Adjustment 33
Sensor Cleaning 34
Fold Plates - Maintenance 34
DocuFold Pro
PAPER
FOLDER
