MORPHO SAFRAN - Page 10

User Guide Presentation
Page 8
2014
SSE-0000101061-03
Morpho Document - Reproduction and Disclosure Prohibited.
TOP SIDE
RIGHT SIDE
#
Device
Use
1
Cover for Contact
Smartcard Reader
2
Cover for SAM slot
3
Contact smartcard
reader
To read smart cards.
4
SAM slot
To read a SAM card with encryption.
5
USB host
To connect USB peripherals, e.g.
keyboard.
#
Device
Use
1
Microphone
Audio input for the device.
2
MicroUSB
To connect the device to a PC or for
battery charging.
3
Audio jack (3.5 mm)
Audio output/input peripheral.
4
Power ON / OFF
button
To switch ON / OFF the device.
5
Volume UP / DOWN
keys
To increase or decrease the volume.
