Technical Specifications
WIRELESS CONNECTION
1. Wireless
 SIM slot supports 2G and 3G network (voice and data).
 Wi-Fi 802.11 b/g/n and Low Energy BT 4.0.
2. Datalinks
 GPRS, EDGE, UMTS, HSPA (HSDPA and HSUPA).
3. GPS
 GPS/QZSS/SBAS -165 dBm tracking sensitivity.
 A-GPS and EPO (Extended Prediction Orbit 30 Days).
DATA CAPTURE
1. Front facing Camera
 1.3MP.
2. Rear facing Camera
 5.0 MP Auto Focus with LED Flash.
3. Signature Capture
 Pen stylus support (Capacitive).
SENSORS
1. Gyroscope
 Maintains orientation based on principles of conservation of
angular momentum.
2. Ambient light sensor
 Automatically adjusts display brightness, keypad and display
backlight.
3. Vibration Sensor/Motor
 Enables to keep the device in vibration mode.
4. Accelerometer
 Enables motion-sensing apps.
5. Fingerprint sensor
 Optical, 500 dpi, 256 grayscale, 14x22 mm capture area.
 FBI PIV IQS and STQC certified.
CARD INTERFACES
1. Contact Card
 ISO 7816 USB interface.
2. Contactless/NFC
 EMV Contacless ISO 14443 A/B Reader.
 NFC: all 4 types of tags (Integrated) ISO/IEC 18092
Reader/Writer.
1) Type 1 & 2 (based on ISO/IEC 14443-A)
2) Type 3 (based on JIS 6319-4, FeliCa)
3) Type 4 ( based on ISO/IEC 14443 standard series, Comm
Interface A or B).
 Contactless: Supports MIFARE Classic - Ultra Light DESFire.
3. SAM Slot
 Enhances the security and cryptography performance.
Enables to perform secure transactions.
SECURITY
1. Security Element
 Tamper resistant secure element.
2. Crypto-processor
 H/W based security schemes - 2048 bit PKI, 256 bit AES, Base64,
SHA 256, 3DES.
3. Fingerprint sensor
 On-board as per CBM E2 standards.
