Morso 2B Classic - Unpacking the Stove; Checking Loose Parts in the Stove

5
1.1 Unpacking the stove
2B Classic: After removing the outer packaging, atten it and lay onto the oor close to the
stove; this can then act as protective work surface during the assembly process.
Next, remove the legs and bolts from inside the stove. Gently lay the stove onto its back and
unscrew it from the wooden pallet. Using the bolts supplied, now screw the legs into position
on the underside of the base. The stove should now be lifted and moved into the upright posi-
tion, avoiding excess load on the back legs.
1.2 Checking loose parts in the stove
After unpacking, check that the re bricks are rmly in position and have not shifted in tran-
sit. Check also that the air control works freely.
Before starting the initial re, make sure that the bae (1) and insulation (2) over the bae
are placed correctly, as shown on the images below. Also check that the cover (3) identica-
tion number 2118 are placed correctly.
