Morso 8140 - Parts Diagram; Parts List

2322
3.5 Parts diagram for model Morsø 8100 3.6 Parts list for model Morsø 8100
Posnr. Parts: 8140 NA 8142 NA 8141 NA 8147 NA 8148 NA 8150 NA 8151 NA
W. drawer incl. turnable Pedistal incl. Pedistal Soapstone Soapstone
base 90° turneble base
90°
64810621 64810721 64811021 64811121 64811221 64810821 64810921
1 Top plate, outside 448110xx 448110xx 448110xx 448110xx 448110xx % %
2 Top frame 448107xx 448107xx 448107xx 448107xx 448107xx % %
3 socle, high 448111xx % 448111xx % % % %
4 Front frame 448131xx 448131xx 448131xx 448131xx 448131xx 448131xx 448131xx
5 Door 448103xx 448103xx 448103xx 448103xx 448103xx 448103xx 448103xx
6 Side plate, right 44810400 44810400 44810400 44810400 44810400 44813300 44813300
7 Side plate, left 44812300 44812300 44812300 44812300 44812300 44813400 44813400
8 Rear plate, inside 44810500 44810500 44810500 44810500 44810500 44812600 44812600
9 Base plate, inside 44812200 44810100 44812200 44812200 44812200 44812200 44812900
10 Top plate, inside 44810600 44810600 44810600 44810600 44810600 44810600 44810600
11 Side plate, outside 448108xx 448108xx 448108xx 448108xx 448108xx % %
12 Rear plate, outside 448109xx 448109xx 448109xx 448109xx 448109xx % %
13 Intermediate frame 34811300 34811300 34811300 34811300 34811300 34811300 34811300
14 Brick, back 79810200 79810200 79810200 79810200 79810200 79810200 79810200
15 Brick, side, right 79810300 79810300 79810300 79810300 79810300 79810300 79810300
16 Brick, side, left 79810400 79810400 79810400 79810400 79810400 79810400 79810400
17 Flue collar 443441xx 443441xx % % 443441xx 443441xx 443441xx
19 Stop bar 544541 544541 % % 544541 544541 544541
20 Screw 731630 731630 731630 731630 731630 731630 731630
21 Ceramic glass 79810100 79810100 79810100 79810100 79810100 79810100 79810100
22 Cover 442610xx 442610xx 442610xx 442610xx 442610xx 442610xx 442610xx
23 Flat bar 545006 545006 545006 545006 545006 545006 545006
24 Distance tube 545007 545007 545007 545007 545007 545007 545007
25 Screw 731620 731620 731620 731620 731620 731620 731620
26 Screw 791835 791835 791835 791835 791835 % %
27 Air canal, rear 44811600 44811600 44811600 44811600 44811600 44811600 44811600
28 Air adaptor 44142600 44142600 % % 44142600 44142600 44142600
29 Air canal, top 448117xx 448117xx 448117xx 448117xx 448117xx 348117xx 348117xx
30 Washer 791891 791891 791891 791891 791891 791891 791891
31 Screw % 731625 % % % % %
32 Screw 731608 731608 % % 731608 % %
33 Glass fitting 71814561 71814561 71814561 71814561 71814561 71814561 71814561
34 Screw 742508 742508 742508 742508 742508 742508 742508
35 Riddling grate 44182800 44182800 44182800 44182800 44182800 44182800 44182800
36 Sek. draught control 71814400 71814400 71814400 71814400 71814400 71814400 71814400
37 Handle f. draught control 71810761 71810761 71810761 71810761 71810761 71813561 71813561
38 Screw 73851000 73851000 73851000 73851000 73851000 73851000 73851000
39 Closing plate 71810600 71810600 71810600 71810600 71810600 71810600 71810600
40 Air canal, front 44811500 44811500 44811500 44811500 44811500 44811500 44811500
41 Tertiary box 71810861 71810861 71810861 71810861 71810861 71810861 71810861
42 Baffle plate, bottom 79810500 79810500 79810500 79810500 79810500 79810500 79810500
43 Cover 448120xx 448120xx % % 448120xx % %
44 Baffle plate, top 79810600 79810600 79810600 79810600 79810600 79810600 79810600
45 Distance tube 71810300 71810300 71810300 71810300 71810300 71810300 71810300
46 Distance tube 71810200 71810200 71810200 71810200 71810200 71810200 71810200
47 Screw 74162000 74162000 74162000 74162000 74162000 74162000 74162000
48 Screw 731635 731635 731635 731635 731635 731635 731635
49 Fitting plate 71811161 71811161 71811161 71811161 71811161 71811161 71811161
51 Screw 731612 731612 731612 731612 731612 731612 731612
52 Riddling bar 53001500 53001500 53001500 53001500 53001500 53001500 53001500
53 Bush 752621 752621 752621 752621 752621 752621 752621
54 Knob f. riddling bar 752619 752619 752619 752619 752619 752619 752619
55 Ash tray 71811300 71811300 71811300 71811300 71811300 71811300 71811300
58 Bush 71813061 71813061 71813061 71813061 71813061 71813061 71813061
59 Hinge pin 54819900 54819900 54819900 54819900 54819900 54819900 54819900 60
Screw 739606 739606 739606 739606 739606 739606 739606
62 Washer 746106 746106 746106 746106 746106 746106 746106
63 Handle 54812800 54812800 54812800 54812800 54812800 54812800 54812800
64 Fitting f. closing plate 71813300 71813300 71813300 71813300 71813300 71813300 71813300
65 Hinge pin 74701000 74701000 74701000 74701000 74701000 74701000 74701000
66 Hinge pin 71810100 71810100 71810100 71810100 71810100 71810100 71810100
67 Screw 73851100 73851100 73851100 73851100 73851100 73851100 73851100
68 Screw 74361000 74361000 74361000 74361000 74361000 74361000 74361000
69 Radiant shielding, bottom 71810400 71810400 % % % 71810400 %
