MoTeC Appendices 53
Pin Name Function
Analogue Temp Inputs
34 AT1 Analogue Temp Input 1
35 AT2 Analogue Temp Input 2
36 AT3 Analogue Temp Input 3
37 AT4 Analogue Temp Input 4
38 AT5 Analogue Temp Input 5
39 AT6 Analogue Temp Input 6
41 AT7 Analogue Temp Input 7
42 AT8 Analogue Temp Input 8
Switch Inputs
57 SW1 Switch Input 1
58 SW2 Switch Input 2
Digital Inputs
52 DIG1 Digital Input 1
53 DIG2 Digital Input 2
54 DIG3 Digital Input 3
55 DIG4 Digital Input 4
Speed Inputs
63 SPD1 Speed Input 1
64 SPD2 Speed Input 2
65 SPD3 Speed Input 3
66 SPD4 Speed Input 4
Auxiliary Outputs
9 AUX1 Auxiliary Output 1
To Next Page
