54 Appendices
Pin Name Function
10 AUX2 Auxiliary Output 2
11 AUX3 Auxiliary Output 3
12 AUX4 Auxiliary Output 4
13 AUX5 Auxiliary Output 5
14 AUX6 Auxiliary Output 6
8 V Sensor
62 8V Sensor 8 V
5 V Sensor
18 5V Sensor 5 V
28 5V Sensor 5 V
44 5V Sensor 5 V
0 V Sensor
6 0V Sensor 0 V
17 0V Sensor 0 V
27 0V Sensor 0 V
33 0V Sensor 0 V
40 0V Sensor 0 V
43 0V Sensor 0 V
51 0V Sensor 0 V
56 0V Sensor 0 V
61 0V Sensor 0 V
CAN Interface
73 CAN1L CAN 1 Low
74 CAN1H CAN 1 High
75 CAN2L CAN 2 Low / RS232 Ground Input
