MoTeC Appendices 55
Pin Name Function
76 CAN2H CAN 2 High / RS232 Receive Input
71 CAN3L CAN 3 Low
72 CAN3H CAN 3 High
59 CAN4L CAN 4 Low
60 CAN4H CAN 4 High
Ethernet
68 E-TX- Ethernet Transmit -
67
E-TX+ Ethernet Transmit +
78 E-RX- Ethernet Receive -
77
E-RX+ Ethernet Receive +
RS232
70 RS232-1 TX RS232 Transmit Output
79 RS232-1 RX RS232 Receive Input
15 RS232-2 TX RS232-2 Transmit Output
16 RS232-2 RX RS232-2 Receive Input
Reserved
29
30
31
32
