Appendix G: E888 Pin List by Pin Number
The E888 uses a 34 + 26 pin connector pair with the following pin-out:
Pin Function Pin Function
A1 TC1+ B1 PWM1
A2 TC1- B2 PWM2
A3 TC2+ B3 PWM3
A4 TC2- B4 PWM4
A5 TC3- B5 PWM5
A6 CJC1 B6 PWM6
A7 CJC2 B7 PWM7
A8 B8 BATTERY +
A9 B9 BATTERY +
A10 BATTERY- B10 DIG2
A11 BATTERY- B11 DIG1
A12 TC4+ B12 DIG5
A13 TC4- B13 PWM8
A14 TC3+ B14 0V COMMS
A15 0V B15 BATTERY-
A16 8V B16 BATTERY-
A17 BATTERY+ B17
A18 TC5+ B18 DIG4
A19 TC5- B19 DIG3
A20 TC6+ B20 5V
A21 TC6- B21 0V
A22 AV1 B22 8V
A23 AV2 B23 CAN HI
A24 AV3 B24 CAN LO
A25 AV4 B25 DIG6
A26 TC7+ B26
A27 TC7-
A28 TC8+
A29 TC8-
A30 AV5
A31 AV6
A32 AV7
A33 AV8
A34 5V
