Appendix H: E816 Pin List by Pin Number
The E816 uses a 66 pin autosport connector with the following pin-out:
Pin Function
(E816B)
Pin Function
(E816B)
1 34 PWM8
2 PWM7 35 CJC1
3 PWM6 36 8V
4 37 BATTERY+
5 AV11 38 BATTERY+
6 AV10 39 BATTERY+
7 PWM5 40
8 41 DIGITAL IN 5
9 AV9 42 DIGITAL IN 6
10 43
11 AV12 44 AV14
12 0V COMMS 45 8V
13 BATTERY- 46 5V
14 BATTERY- 47 CAN LO
15 BATTERY- 48
16 PWM4 49 PWM3
17 CJC2 50
18 0V 51
19 BATTERY- 52 AV15
20 BATTERY- 53 5V
21 BATTERY- 54 CAN HI
22 BATTERY- 55
23 DIGITAL IN 1 56 PWM2
24 DIGITAL IN 2 57 AV16
25 58 AV1
26 AV13 59 AV2
27 0V 60 AV3
28 BATTERY+ 61 PWM1
29 BATTERY+ 62 AV4
30 BATTERY+ 63 AV5
31 64 AV6
32 DIGITAL IN 3 65 AV7
33 DIGITAL IN 4 66 AV8
