16
Example:
Test Condition:
Frequency : 1KHz
Level : 1Vrms
Speed : Slow
DUT : 100nF
Then
Ω=
⋅⋅⋅⋅
=
⋅⋅⋅
=
−
1590
10100102
1
2
1
93
π
π
Cxf
Zx
Refer to the accuracy table, get
Z
Ae
=±0.2%,
deg115.0
100
2.0180
100
Ae180
Ae
±=⋅
π
±=
⋅
π
±=θ
 Testing Signal:
Level Accuracy : ± 5%
Frequency Accuracy : 0.1%
 Output Impedance : 100 Ω ± 5%
 Measuring Speed:
Fast : 4.5 meas. / sec.
Slow : 2.5 meas. / sec.
