Motech MT 4080 - Specification

6
1.3 Specification
 LCD Display Range:
Parameter Range
Z
0.000
Ω to 9999 M Ω
L 0.000 µH to 9999 H
C 0.000 pF to 9999 F
DCR
0.000
Ω to 9999 M Ω
ESR
0.000
Ω to 9999 Ω
D 0.000 to 9999
Q 0.000 to 9999
θ
-180.0
° to 180.0 °
Figure 1.2
Real and imaginary components are serial
ss
jXRZ
+
=
R
s
jX
s
Real and imaginary components are Parallel
G=1/R
p
j
B=1/jX
p
jBGY
+
=
j
X
p
R
p
P
jX
1
P
R
1
Y +=
