Contents
1. INTRODUCTION ............................................................. 1
1.1 G ENERAL .......................................................................... 1
1.2 I
MPEDANCE P ARAMETERS ................................................ 3
1.3 S
PECIFICATION .................................................................. 6
1.4 A
CCESSORIES ................................................................. 19
2. OPERATION ................................................................... 20
2.1 P HYSICAL D ESCRIPTION ................................................. 20
2.2 M
AKING M EASUREMENT ............................................... 21
2.2.1 Battery Replacement ............................................................... 21
2.2.2 Battery Recharging/AC operation.......................................... 22
2.2.3 Open and Short Calibration ................................................... 23
2.2.4 Display Speed.......................................................................... 24
2.2.5 Relative Mode ......................................................................... 24
2.2.6 Range Hold ............................................................................. 24
2.2.7 DC Resistance Measurement.................................................. 25
2.2.8 AC Impedance Measurement.................................................. 25
2.2.9 Capacitance Measurement ..................................................... 25
2.2.10 Inductance Measurement........................................................ 26
2.3 A CCESSORY O PERATION ................................................. 27
3. INFRARED OPERATION............................................. 29
3.1 C OMMAND S YNTAX ........................................................ 30
3.2 C
OMMANDS .................................................................... 31
4. APPLICATION ............................................................... 39
4.1 T EST L EADS C ONNECTION ............................................. 39
4.2 O
PEN /S HORT C OMPENSATION ........................................ 44
4.3 S
ELECTING THE S ERIES OR P ARALLEL M ODE ................. 46
5. WARRANTY INFORMATION ..................................... 49
6. SAFETY PRECAUTION ............................................... 51
