26
the D and Q can be shown on the secondary display. The following
shows some examples of capacitance measurement:
The testing level and frequency can by selected by pressing the
Level key and Frequency key, respectively.
2.2.10 Inductance Measurement
Select the L/C/Z/DCR key to Ls or Lp mode for measuring the
inductance in serial mode or parallel mode. If the serial mode (Ls)
is selected, the D, Q and ESR can be shown on the secondary
display. If the parallel mode (Lp) is selected, only the D and Q can
be shown on the secondary display. The following shows some
examples of capacitance measurement:
The testing level and frequency can by selected by pressing the
Level key and Frequency key, respectively.
