MOTECK CI73 - 2. Power Input Terminals; 3. Actuator Terminals (With Potentiometer)

2. Power input terminals
3. Actuator terminals
(1) With Potentiometer
www.moteck.com
3
Port Description
Wiring:
Actuator extends
7 5 6
• 24V DC output, 10A max.
• When controlling the actuator to extend, M+ / M- are VDC+ / VDC-
respectively. When retracting the actuator, the polarity is reversed.
5
6
GND
5V output to actuator's Potentiometer
Voltage (POT value) input
7
4
3
Definition DescriptionPort
V
-
• GND
• Recommend to use a 2-core 18AWG power cord
(depending on the current)
2
V+
• Nominal 24V DC (acceptable input voltage range 20V ~ 32V DC)
• Recommend to use a 2-core 18AWG power cord
(depending on the current)
1
Definition
G
Vcc
P
M-
M
+
2
1
6
5 4 3
7
