MOTECK CI73 - 4. Actuator Terminals (With Hall Effect Sensor)

www.moteck.com
4
(2) With Hall effect sensor
5
GND
5V power output, for actuator's Hall module.
Both types are acceptable
Hall 1 input
Hall 2 input
9
8
Hall signal data: Actuator extends
• A-type • B-type
Hall 1
Hall 2
High
Low
High
Low
Hall 1
Hall 2
High
Low
High
Low
Port Description
• 24V DC output, 10A max.
• When controlling the actuator to extend, M+ / M- are VDC+ / VDC-
respectively. When retracting the actuator, the polarity is reversed.
4
3
6
G
Vcc
H1
H2
Definition
M-
M
+
Remarks: For single actuator mode, please use only terminals .
9
6 5
4 3
9 8
